Lake People F811

Product description

Balancing, impedance and level matching unit for interfacing between consumer- and studio equipment.

- 2 x 4 identical sections from consumer level to studio level
- Rear inputs via Cinch (RCA) sockets
- Front inputs via Cinch (RCA) sockets with priority
- All inputs with gold plated contacts
- Inputs optimized for “-10 dBu” signals
- Impedance 50 kohms
- Internal filters to reduce the bandwidth to a safe and useful range: 5 Hz … 70 kHz (-1 dB)
- Front accessible multiturn trimpots for level adjustment with a range from -3 … +21 dB
- Balancing of the output signals with optimized circuits for highest resistance- and common mode rejection ratio (CMRR)
- Output impedance 30 Ohms according to IRT rules
- XLR type output sockets with gold plated contacts
- 19”, 1 U stainless steel case, front color dark grey

Option:
Outputs with “active feedback” transformers (up to 8 tranformers may be installed)
